Problem solving and object of study: Vehicle-mounted energy storage guideway tram is a four-group guided tram designed, developed and manufactured independently by CRRC SIFANG CO., LTD. based on years of vehicle design and manufacturing experience. The design fully considers the user's operating conditions, maintenance conditions and operating habits, and has the characteristics of compact structure, lightweight, functional modules and system integration. Vehicle-mounted energy storage guideway tram is a four-group 100% low floor tram.The maximum gradient can be less than 13% by adopting rubber wheel drive, load bearing and single rail wheel steering mode. Articulated body structure and interconnection of the living room.Ultra-capacitor power supply, low noise, no burning waste gas, no overhead power grid, avoids visual pollution, can achieve zero emissions, effective reduction of air pollution. It fully embodies the travel concept of green, energy-saving and environmental protection of modern transportation.The minimum horizontal curve radius is R15m, and the maximum operating speed is 80km/h under rated conditions，short braking distance effectively guarantees safe vehicle operation and passenger travel safety.The materials used in the parts have good flame retardancy, corrosion resistance, wear resistance and high temperature resistance.It has sufficient strength and stiffness and meets the requirements of relevant standards，s electronic control air suspension system, aviation grade interior material and shock absorption structure design can ensure the safety and reliability of guideway tram. The process of thinking： The design of Vehicle-mounted energy storage guideway tram takes full account of safety,reliability, general interchangeability of system and components, serialization, standardization, modularization, and overall lightweight, combining with local line conditions and operation environment. Design highlights and color analysis: In the aspect of design, the local conditions and complex operating environment of customers are fully considered, the design requirements of humanization, safety and intelligence are highlighted, and the characteristics and characteristics of products are highlighted. The driver's cab head cover is integrated, the control platform layout is reasonable, meets the ergonomics, the field of vision is calculated to meet the standard requirements; the passenger room layout is reasonable, and the ride is comfortable and convenient. Head lines are smooth ,the main color of the front is silvery white, which reflects the sense of modern science and technology. The yellow color gives people a sense of lightness and vitality, reflects the lightweight and power of the vehicle. The front is two symmetrical dragon-shaped patterns, sparks run through the body from the tail. This scheme is based on the dragon dance culture of the intangible cultural heritage of the local country.The interior is designed in a retro style. The surface of seats, passages and end walls is treated with wood grain. The walls and roofs are white. The color is taken from the wood structure and white walls of Anju ancient town. The bronze armrest echoes the interior decoration. The whole interior creates an antique riding environment, and through color matching, it adds a sense of hierarchy. In the field of art, waterborne paint is used for the painting of car body and headgear, which is more safe and environmentally friendly. Water transfer printing is used to treat the wood grain inside the car, which not only realizes the beauty of the surface of the parts, but also has the advantages of corrosion resistance, wear resistance and environmental protection. The surface hardness of 6H is higher than that of 3H paint. The whole scheme not only embodies the modern aesthetic feeling, but also conforms to the local regional cultural characteristics.

not available

In 2016, 16 contracts for four groups of vehicles were signed, with sales revenue of 320 million. With the help of this project, the company has been expanding its achievements in market development and technology to achieve its own development while driving the development of the industry. With its special traffic mode, unique technical characteristics and system operation mode, guided tram provides a new choice for domestic urban public transport, and opens the "rubber wheel era" of urban public transport system. As a medium-volume public transport system, rubber-tyred guided tram has the advantages of smaller area, less impact on other vehicles, shorter construction period and lower maintenance cost. It is the preferred tool for effectively utilizing urban space. It has broad market prospects and huge space.

not available

CRRC SIFANG CO., LTD is a wholly owned subsidiary of CRRC CORPORATION LIMITED，The company registered for No.9 Hongping Road,Chengyang District,Qingdao City,Shandong Province,and registered capital 343.1 million ,total corporate assets 6.188 billion.The company is now mainly engaged in High-end railway carriage,manufacture and repair of High-Speed EMU Unit(Joint venture),all kinds of railway locomotive,city rail subway and other rail transport equipment repair,installation and reform, road-rail dual vehicle and various kinds of railway special vehicles,railway locomotive carriage and energy equipment accessories manufacturing,motor vehicle technical services,logistics,import and export and new materials business. Innovation platform construction situation and achieve industrial design performance：The company applied to city industrial design center in 2015 and provincial industrial design center in 2016,and complete 11 industrial design projects,and apply 8 patents for design. Future Development Goals:The company insists on combining design innovation and technological innovation.Improve industrial design independent innovation ability.Enhance industrial design industrialization development level.Support industrial design innovation industrialization. Continuous technological innovation as the power source of enterprise development,adhere to the development trend of industry technology.Lead research directions with effective market demand,promoting sustainable development of enterprises.Further enhance the company＇s actual industrial design capability,and accelerate the development of industrial design.
