袋鼠爸爸V106
EuroKids V106
产品 儿童安全汽座 7258 0 2018-12-21
点赞(0) 收藏(0)
作品详情
中文 / English
作品简述
袋鼠爸爸V106是由麦克英孚(宁波)婴童用品有限公司全程自主设计、研发及生产的儿童安全座椅产品。我司是国内最早获得欧洲ECER44、北美FMVSS213和德国莱茵TUV质量体系认证的儿童安全座椅制造企业。我公司也是目前中国地区最大的“汽车儿童安全座椅”研发企业和制造商。 袋鼠爸爸V106产品提供在汽车行驶过程中对儿童的保护,适用于新生至六岁左右儿童(Group:0+/1/2,0-25KG)。 本产品正向和反向双向安装均可使用ISOFIX接口或者车载安全带方式,适用于大部分车型,其反向安装时间长达至宝宝15个月。符合人机工程学的睡舱式内衬托垫,能让宝宝在反向安装中以舒适的角度睡眠,同时在汽车行驶的颠簸路途中更好的托住宝宝娇嫩的脊椎。强大的椅背和头枕侧面保护,加强了在侧面碰撞时对宝宝的保护。 本产品在双层外观壳体与之相应的产品结构方面实现技术创新,从结构的角度就已降低了在汽车碰撞时对儿童的伤害。其中椅背释锁机构和头枕肩带调节方式已申请国家发明专利。 造型圆润简洁,蛋壳造型寓意对新生宝宝全方位的呵护。
用户价值
本产品不止为新生至六岁提供出行安全服务并满足儿童多变的乘车习惯:睡姿、坐姿、躺姿;适用于市面上的几乎所有车型;为用户提供了更加便捷的安装ISOIFX安装方式,柔软舒适的面料贴心的为婴幼儿的创造了舒适安全的行车旅程。 产品外观的蛋壳型椅仓与底座分离式切换这一结构设计解决了消费者在使用正反向安装切换时需要再次重复安装的问题,降低了误操作的风险。 同时椅舱蛋的壳型外观是使用一体注塑成型技术,该造型设计及制作工艺中克服了U型面脱模的技术难点,加之内部吹塑工艺的双层壳体结合有效的在结构及材料层面优化了儿童安全座椅在碰撞时所产生的冲击力对儿童的伤害。 配合高效吸能的HDPE材料,高韧性PP材料,高强度的PA材料,全身关键零部件采用恒温压的注塑工艺一次成型,防冲撞、耐高温、耐高压。 该产品从外观饱满的设计到功能便捷吸引用户,打破安全座椅操作复杂,购买后使用率低的实用壁垒。解放了父母的双手,让父母安心享受与孩子共同出行的乐趣。
社会影响
关于安全座椅的普及: 作为安全座椅普及率低于1%的国家,我们不但是安全座椅的设计研发生产者,我们同样也愿意成为安全意识普及道路上的一颗螺丝钉。并且为推动相关法规中,让孩子在行车安全途中更安全尽到自己的一份力。 环保性: 1.产品每个零件,除了达到中国环保法规标准外也同时通过欧盟等国际环保标准。 2.在满足产品安全和功能性能的一系列前提下,对产品的生产一致性进行严格的管控,基于环保的理念,我们对产品的材料进行可循环利用评估和应用。 3.环保材料的运用,给座椅及婴童行业树立了榜样,将引领安全座椅行业进入全方位呵护婴幼儿的阶段。
团队组织
整个项目从立项到量产,参与部门众多,前期主要有品牌、销售、设计、工程等部门,后期质量、制造、供应商等都加入了项目的研发生产验证工作,总共参与人数有50人之多,品牌、销售主要负责项目的立项,功能和外观的确定,设计主要负责项目外观、结构等的设计工作,工程主要负责项目的开发工作,质量、制造、供应商负责项目的试验、试量产等工作。各个部门之间既有分工,更有合作,使得座椅能够按时保质保量的完成。
流程方法
1.在大型塑料件工艺上采用吹塑与注塑结合的方式,保证了强度、安全性和品质感; 2.纺织设计采用了创新的睡舱式内衬垫和局部可拆洗式头枕,更周全的呵护新生儿的; 3.延续系列产品重要结构产品部件以增加可靠性和节约成本
达成情况
优秀的产品品质与性价比获得国内外客户的好评和消费者青睐。 精准的流程管控使得产品的预算成本和流程计划都顺利达成,有着乐观的市场前景。 拥有5项国家专利,1个外观专利,4个实用型专利。
Project Description
EuroKids V106 is a child safety car seat designed, developed and produced by Max-inf (Ningbo) Baby Products Co., Ltd. Max-inf is the earliest car seat manufacturer that has obtained European ECER44, North American FMVSS213 and TUV Rheinland quality system certification. Max-inf is also the largest R&D enterprise and manufacturer of “Child Safety car Seats” in China. EuroKids V106 is a 0+/1/2 group car seat for newborns up to 25 kg. It is suitable for children aged 0-6 years. It is safe for children and brings relaxation to the whole family. Both the forward and reverse installation of this product can use ISOFIX interface or car seat belt. Reverse installation time up to 15 months for your baby. Specially designed sleeping cushion is ergonomically designed to hold your baby's delicate skin and spine. The powerful back of the seat and the side protection of the headrest further enhance the protection of the baby. The double-layer plastic shell, together with the internal energy absorbing material and the composite laminated cover, effectively absorbs the impact energy generated during the collision, and it is safer and more secure. In order to adapt to children of different heights,Headrests and seat belt heights can be linked to stepless adjustments. The special seat back release mechanism and headrest shoulder strap adjustment method have applied for national invention patents. The shape is round and simple, the eggshell shape means the full care of the newborn baby.
User Value
It meets the needs of children aged 0-6 and meets the changing habits of children: sleeping, sitting, lying positions; suitable for almost all models on the market; providing users with more convenient ISOFIX installation methods, soft and comfortable fabrics Intimately creates a comfortable environment for baby. The seat shell design is separated from the base. This structural design solves the problem that the consumer needs to repeat the installation again when change the forward and reverse installation, which reduces the risk of misoperation. The eggshell appearance of the seat is the use of integrated injection molding technology, which overcomes the technical difficulties of U-shaped demoulding in the design and manufacturing process. The combination of the double-shell structure and material effectively reduces the damage to the child during the collision of the seat. High efficiency energy absorption HDPE material, high Tough PP material, high-strength PA material, key parts of the whole body are formed by one-time injection molding process with constant temperature pressure, anti-collision, high temperature resistance and high pressure resistance. The car seat appeals to users from a full-fledged design to a convenient function. Break the practical barriers of complicated seat operation and low usage rate after purchase. Liberates the parents' hands and enjoys the safety travel of the whole family.
Business Performance
The design, development and production of this product are in full compliance with the national GB27887-2011 and European ECE R44 car seat standards, and the goal is excellent C-NCAP evaluation. EuroKids V106 is based on the two criteria of excellent product quality and absolute cost performance. The retail price of the product will be less than RMB 1,000, which is about half of the international brand price. It is estimated that the annual sales in China will be 10,000 units, and there will be orders from overseas markets afterwards. V106 adheres to the cultural concept of the brand of Eurokids: “Being perfect and helping others” – giving consumers “safety and high cost performance”, while the brand of EuroKids is appreciated by consumers.
Social Impact
About the popularity of safety seats: China's safety car seat usage rate is less than 1%. We are not only the design and development of safety seat manufacturers, but also promote the popularity of safety awareness. And kkeep your child safe. Social impact Environmental protection: 1. Each part of the product, in addition to meeting the Chinese environmental protection standards, also passed the international environmental standards such as the European Union. 2. Under the premise of satisfying product safety and functional performance, we strictly control the production consistency of our products. Based on the concept of environmental protection, we conduct recyclable evaluation and application of the material of the product. 3. The use of environmentally materials has set an example for the seat and baby industry, and will lead the safety seat industry into the stage of comprehensive care for infants and young children.
Team Structure
The whole project has a large number of participating departments from project establishment to mass production. In the early stage, there were mainly brands, sales, design, engineering. Later quality, manufacturing, and suppliers all joined the R&D and production verification of the project. The total number of participants was 50. Brand and sales are mainly responsible for project establishment, function and appearance determination, design is mainly responsible for appearance, structure and other design work, the project is mainly responsible for project development work, quality, manufacturing, supplier responsible for project testing, trial Mass production and other work. There is a division of labor and cooperation between the various departments, so that the seats can be completed on time with high quality.
Flow
1. The combination of blow molding and injection molding on the process of large plastic parts ensures the product is strength, safety and highly quality; 2. The textile design adopts the innovative sleeping cabin inner insert and removable headrest, more comprehensive care for newborns. 3. Continue the series of important structural product components to increase reliability and cost savings
Project Achievements
Excellent product quality and cost performance have won praises from domestic and foreign customers. Accurate process control makes the product's budget cost and process plan reach smoothly, with optimistic market prospects. Have 5 national patents, 1 appearance patent, 4 practical patents
