The portable ground penetrating radar uses ultra-thin integrated design, with the characters of small size, light weight, low-power circuits, easy to carry and good adaptability. Compared with traditional products, it has high level of intelligence, using WinCE platform real-time control software, starts faster; high-speed DSP embedded, to achieve filtering, amplification and other real-time processing. With the characters of high speed detection, non-destructive, high resolution image, real-time imaging and so on. The radar is equipped with ANDROID operating system, with 10.4 'large screen. Windows-based operating system developed radar software of Chinese interface, easy to start to use and operate; Digital programmable clock control, the minimum time is interval 10ps, provides real-time images display directly. It provides an effective solution to the use of digital products with reliability, stability and ease of problem in wet, harsh environment field, tunnels and so on. Considering the usage environment and the relationship between products and people, designers used the encapsulation treatment design to achieve antiskid function and enhance the reliability with a high integration, rigorous design style. We pay attention to the protection of products and a sense of solid shape. The aluminum alloy oxidation body design brings quality feels and ensure the performance in heat radiation. Backlight waterproof button design meets the needs of harsh usage environments. The durability design of laser mark suits aluminum alloy oxidation body well, and meets the high-end product market positioning.

Considering the usage environment and the relationship between products and people, designers used the encapsulation treatment design to achieve antiskid function and enhance the reliability with a high integration, rigorous design style.Windows-based operating system developed radar software of Chinese interface, easy to start to use and operate.

The innovative design of the radar has made a qualitative breakthrough in the concept of the past product, in terms of appearance design, structural design, material selection, product processing and other aspects, set up a new image of the industry's products, making the brand reputation be better spread. At present, we plan to participate in the exhibition overseas with this product and gradually open the international ground penetrating radar market.

Chief designer: Zhaokun Yang Other designers: Yousheng Sun

With the extensive application of ground penetrating radar in transportation, geological prospecting, construction, water conservancy, municipal, archeology and so on, PinkeDesign Co., Ltd is considering how to improve the product in the traditional products in the stability, handling, portability and other properties to match the leading products of worldwide, and enhance the international reputation and influence.

After six months systematic development, we finished the hardware and software selection, optimization step by step on the stage of the industrial design, then we pay a lot time to test the prototype on the stage of structural design. The final model of the product prototype was finished at the end of 2015. Once the product is listed, it has been greatly recognized and praised by domestic and foreign counterparts and became a leading product in the portable ground penetrating radar industry.
